- [ PIR Human Detection ]Â Â 6 foot PIR detection, more accurate detect, efficiently reduce the invalid alarm, which can efficiently filter the invalid alarm caused by curtain swing, light change, non-human passing, shacking, etc. When detects human movement, the camera will immediately alarm you by your mobile phone.
- [3000mAh Battery ] Compare to other brand camera, NCJ CB75 camera is built-in 3000mAh rechargeable battery, with one time full charge the standby time can be reach up to 2 years, lower power consumption. USB power interface, it can be charged by the computer, the power bank or the socket outlet, easy to get full charged.
- [ 1080P FULL HD RESOLUTION ]Â 1/3 inch 1080p progressive scan CMOS sensor adopted, super clear visual experience, just like what you see with your own eyes. 30fps frame rate, super stable and smoothly video playing, no stuck any more. 8pcs 940 nm IR Leds without exposure infrared light. The night vision ranges up 10 meter.
- [ 4G Micro SIM Card Network & DV mode ] 4G LTE network supply, no worry about slow network or poor wifi coverage. Turn on 4G mode, insert the Micro SIM card, remotely connection the camera with the mobile phone, to remotely monitoring by the mobile phone.Turn on the DV mode, use as the DV recorder or car dash camera.(CB75 only works with Android phone or iOS )
| System | Operation system | Lite OS |
| Online visitor | Support 4 visitors at the same time | |
| APP | O-KAM | |
| Image Capture | Image sensor | GC2083,1/3 inch 1080p progressive scan CMOS sensor |
| Minimum Illumination | 0.3-0.5Lux(color mode), 0Lux(B&W mode) | |
| Lens | 4G lens, IR CUT integrated, standard lens diameter 10mm | |
| View Angle | 135Ëš(Diagonal) | |
| Night vision | Photosensitive filter with auto-switching，8pcs 940nm SMD IR LED,
IR irradiation distance:3~5Â m |
|
| Video | Encode format | H.264+main Profile/H.264 Baseline Profile/MJPEF/JPEG Baseline |
| Streams | 1080P@15fps | |
| Bit Rate | CBR/VBR two rate control modes, and the output rate range is 128～4096kbps | |
| Maximum frame rate | 30fps | |
| Image adjustment | Auto | |
| Audio | Input | Built-in 38db microphone |
| Output | Built-in 8 Ω 1 w speakers | |
| Sampling frequency /
Bit width |
8KHz/16bit | |
| Compression standard /
code rate |
G711A | |
| Network frequency | China Cat 1 | FDD:B1/B3/B5/B8 ; TDD:B34/B38/B39/B40/B41; |
| Overseas Cat 4 | WCDMA：B1/B5/B8 FDD：B1/B3/B5/B7/B8/B20 TDD:B38/B40/B41 | |
| Memory | Socket | TF Push-push socket,Maximum support 256GB; Cloud Storage |
| Alarm | Alarm Trigger | Support Humanoid detection & Motion detection ; PIR detection |
| Physical Environmental | Rated voltage | DC5V±5% |
| Power supply | Built-in 3000mAh batteries/USB DC5V | |
| Power consumption | Sleep mode: 5mAÂ Â Â working mode: 600mA | |
| Operating condition | Temperature:-10～55℃,humidity:＜90% | |
| Weight | Net: 90g  Gross：240g (Note: in kind prevail) | |
| Package size | 130x90x45 mm (L×W×H) |
